AKT MAX (5KW/10KW) ALL-IN-ONE INVERTER

₦7,800,000

Specifications

KEY PRODUCT FEATURES:


Model Name: MAX48102

Inverter Parameter:

Battery Input: 51.2VDC

AC Output: 230VAC, 50Hz, 22A, 1@

Rated Power: 5000VA/5000W

Lithium Battery Module:

Model: SD485

Rated Voltage: 48V

Rated Energy: 5040WH

Rated Capacity: 105Ah

Rated Discharge Current: 120A

Charging Cut-off Voltage: 54.8v(max)

Discharge Cut-off Voltage:42V(min)

IP Level: IP20

Battery Type: LiFePO4

Operating Temperature: -10*C~50*C


PACKAGE INCLUDES:


5KW = 5000W = 5000W Hybrid Inverter

2X5KW = 5040WH X2 = 10080WH Capacity LifeP04 Lithium ion Battery

12X550W Photovoltaic Solar Module

Max Standing Multi Battery

Stackable Hybrid Inverter

Complete Installation Kits and Accessories

LCD Display Screen

Inbuilt Smart Charger Solar system

Moveable Wheels

6000 Deep Life Cycle

BMS Over Voltage Protection, Short Circuit Protection

Easy Installation.

Good Space management

4 Years Warranty


Product Details

AKT MAX (5KW/10KW) ALL-IN-ONE INVERTER


KEY PRODUCT FEATURES:


Model Name: MAX48102

Inverter Parameter:

Battery Input: 51.2VDC

AC Output: 230VAC, 50Hz, 22A, 1@

Rated Power: 5000VA/5000W

Lithium Battery Module:

Model: SD485

Rated Voltage: 48V

Rated Energy: 5040WH

Rated Capacity: 105Ah

Rated Discharge Current: 120A

Charging Cut-off Voltage: 54.8v(max)

Discharge Cut-off Voltage:42V(min)

IP Level: IP20

Battery Type: LiFePO4

Operating Temperature: -10*C~50*C


PACKAGE INCLUDES:


5KW = 5000W = 5000W Hybrid Inverter

2X5KW = 5040WH X2 = 10080WH Capacity LifeP04 Lithium ion Battery

12X550W Photovoltaic Solar Module

Max Standing Multi Battery

Stackable Hybrid Inverter

Complete Installation Kits and Accessories

LCD Display Screen

Inbuilt Smart Charger Solar system

Moveable Wheels

6000 Deep Life Cycle

BMS Over Voltage Protection, Short Circuit Protection

Easy Installation.

Good Space management

4 Years Warranty
